High Temperature Resistance PTFE Tube with Chemical Resistance and Self-Extinguishing Properties for Electronic Use

Merknaam:	None
Modelnummer:	ES5500
MOQ:	1
Prijs:	negotiable
Betalingsvoorwaarden:	L/C, D/A, D/P, T/T, Western Union
Toeleveringsvermogen:	10.000 meter dag

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

Jangsu China

Certificering:

ISO9001

Temperatuurbestendigheid:

-65 tot 260C

Ontvlambaarheid:

UL,VW-1

Isolatie:

Hoog

Chemische weerstand:

zuur-alkalibestendig

Kleur:

Zwart, rood, geel, wit, blauw, roze, paars

Slijtvastheid:

0,05 tot 0,10

Blusvermogen:

Zelfdovend

Elektriciteit:

Hoge elektriciteitsweerstand

Verpakking Details:

Karton

Levering vermogen:

10.000 meter dag

Markeren:

High temperature resistance PTFE tube

Chemical resistant PTFE tubing

Self-extinguishing PTFE tube electronics

Productbeschrijving

PTFE Non-Shrink Tubing

PTFE (Polytetrafluoroethylene) non-shrink tubing, also known as Teflon tubing, is a semi-rigid tube manufactured by extruding and sintering PTFE resin. It is non-heat-shrinkable (shrink temperature ≥ 320°C), maintaining stable dimensions under normal operating conditions.

Key Features

Temperature Range: -200°C to +260°C (continuous use)
Chemical Resistance: Resistant to almost all acids, alkalis, solvents, oxidizers (except fluorine, molten alkali metals)
Electrical Properties: High dielectric strength (≥55kV/mm), low dielectric constant (2.1), high volume resistivity (10¹⁸Ω·cm)
Low Friction: Lowest coefficient of friction among solids (≤0.04), non-stick, easy to clean
Mechanical: High strength, wear-resistant, creep-resistant, aging-resistant
Certifications: RoHS, REACH, FDA food contact compliant
Flammability: UL94 V-0 (self-extinguishing)

Specifications

Color: Natural translucent white, custom colors available
Voltage Ratings: 150V / 300V / 600V
Wall Thickness: Standard, thin, heavy
Sizes: Inner diameter 0.3mm ~ 20mm, custom available

Applications

Electronics: High-temperature wire harness, motor, transformer insulation
Chemical/Semiconductor: Corrosive fluid, high-purity chemical, specialty gas transport
Medical: Catheters, infusion tubes, steam sterilization lines
New Energy: EV battery coolant, high-voltage wire insulation
Aerospace: Extreme temperature, corrosion-resistant tubing
Food/Pharma: FDA-approved food transfer, sterilization line
