Transparent and White Choice Ultra-Thin PTFE Heat Shrink Tubing 1.5mm Engineered For Performance

Merknaam:	NONE
Modelnummer:	1,5 mm
MOQ:	500
Prijs:	negotiable
Betalingsvoorwaarden:	TT In Advance
Toeleveringsvermogen:	200000m/day

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Certificering:

ISO9001

Voeding:

+3.3V

Verlengd:

-65 tot +200°C

Kleur:

Wit en helder

Certificeringen:

Voedselkwaliteit/RoHS/S GS

Diëlektrische sterkte:

22-24 Kv/mm

Geschikt:

MK1100 / MK1500 / MK2100 / MK2500

Sollicitatie:

Scrapbooking gereedschap Vouw vouw gereedschap

Packaging Details:

Carton

Supply Ability:

200000m/day

Markeren:

Ultra-Thin PTFE heat shrink tubing

Transparent PTFE tubing for performance

White PTFE heat shrink 1.5mm

Productbeschrijving

Product Description:

Our Ultra-Thin Wall PTFE Heat Shrink Tubing is engineered for applications where space is limited but extreme performance is required. With a pre-shrink inner diameter of 1.5mm and an ultra-thin wall thickness of just 0.02mm, this tubing provides a lightweight, non-stick insulation layer that can withstand the harshest chemical and thermal environments.

Key Specifications:

Material: Premium PTFE (Polytetrafluoroethylene)
Recoverable ID (Pre-shrink): 1.5 ± 0.2 mm
Recovered ID (Post-shrink): ≤ 0.9 mm
Wall Thickness: 0.02 ± 0.05 mm (Ultra-Thin)
Shrink Ratio: Approx. 1.7:1 (Based on ID change)
Shrink Temperature: 327°C (620°F)
Operating Temperature: -70°C to 260°C (-94°F to 500°F)
Standard Packaging: 200 Meters/Roll

Features:

Ultra-Thin Profile: At only 0.02mm, it adds minimal bulk to fine wires and connectors.
Chemical Resistance: Inert to almost all chemicals, solvents, and acids.
Non-Stick Surface: Prevents adhesion of dust, dirt, or sticky substances.
High Purity: Ideal for medical, food processing, and cleanroom environments.
Flame Retardant: Self-extinguishing (UL VW-1 Rated).

This PTFE product is a high-performance plastic known for its excellent non-stick coatings, making it ideal for various applications. The use of virgin PTFE ensures durability and superior non-stick coatings properties, suitable for continuous operating conditions

Applications:

Insulation for fine gauge wires and micro-components.
Medical devices and sensor protection.
Aerospace and military electronics.
High-temperature wire harnessing where space is critical.
